Description
| Component Description | Specifications |
| Brand | Agrotech |
| Model No | 6LN/15-15/SF |
| Country of Origin | China |
| Capacity | 1,000kg per hour input |
| Voltage | 3 phase 400V 50/60Hz |
| Total power requirement | 25Kw / 60 Amp |
| Pre-cleaning and de-stoning unit | Multi-layer reciprocating vibrating separation mechanism with large capacity blower for proper removal of impurities. |
| Elevators | 02 elevators for paddy loading and product transferring separately. |
| Husker | 06 inch rubber roll husking unit with belt driven system. |
| Paddy separator | Large screen area for high separation speed and even paddy distribution. The horizontal and vertical angles of the screen is adjustable. |
| Rice mill | Emery roll rice mill with large capacity blower for bran separation and reduce temperature inside the mill dimension of emery rolls approximately φ150××400 mm. |
| Broken rice separator | Separate broken rice from good rice. |
| Rice milling rate | Approximately 68 – 72% |
| Broken rice percentage | Less than 2% |
| Power saving | Each section can be operate separately. |
| Construction | Unibody design with MS frame. |
| Dimensions | 3,400××1,500××2,900 mm |
| Weight | 1,350 kg |
| Warranty | 01 year warranty for manufacture defects only |
