Description
| TRACTOR | SPECIFICATION |
| Model | EK3-471, 4WD |
| Make | Escorts Ltd. |
| No. of Cylinders | 3 |
| Total Displacement ( cc ) | 2,761 |
| Engine Gross Power ( HP ) | 47 @2000 rpm |
| PTO Power ( HP ) | 38.0@540/540 E rpm, Independent type |
| Fuel Tank Capacity ( L) | 60 |
| Overall Length (without 3P) ( mm) | 3,245 |
| Overall Width ( mm) | 1,800 |
| Overall Height (from Muffler)
(mm) |
2,380 |
| Wheelbase (mm) | 1,885 |
| Min. Ground Clearance (mm) | 400 (Tie Rod) |
| Dimensions Tread Front (mm) | 1,524 |
| Dimensions Tread Rear (mm) | 1,450 |
| Weight (with Carrier) (kg) | 2,210 |
| Standard Ballast Mass ( kg ) | |
| Clutch | Double Clutch (I – PTO) |
| Front Standrd Tyre | 9.5 x 18 |
| Rear Standrd Tyre | 14.9 x 28 |
| Steering | Power steering |
| Transmission | F8/ R8 Gear, Partial Synchromesh type |
| Brake | Wet disk type (OIB) |
| Turning Radius w/o brake (mm) | 3.11 |
| Traveling Speed ( km/h ) | Foeward 31.11, Backward 31.08 |
| Hydraulic Control System | Draft and Position control |
| Lift Capacity (at lower link end) (kg) | 1530 |
| Lift Capacity (at 610mm behind lifting end) (kg) | 1060 |
| Auxillury Valve | Standard |
| 3-point Hitch | Category I with Combine Ballends (Cat 2 & Cat 1) |
